Mean Well DDRH-30-48ST (30W 48V)
SKU
DDRH-30-48ST
$50.20
- Buy 5 for $47.80 each and save 5%
- Buy 10 for $45.70 each and save 9%
- Buy 20 for $44.40 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, Enclosed Package, 30 Watts, Input Voltage Range: 150~1500VDC, Output Voltage: 48VDC, Output Current: 0.625A
More Details
The MEAN WELL DDRH-30-48ST is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 150 VDC and 1500 VDC with a nominal input of 800 volts. The DDRH-30-48ST has a 48 Volt Output at 0.625 amps (30 watts). The operating temperature is -40~+80°C and comes with several safety marks including EAC/CE/UKCA. The DDRH-30-48ST, DC-DC converter, has a Enclosed package type and its dimensions are 5.31 (L) x 2.76 (W) x 1.26 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL DDRH-30-48ST Features
View More
For specific information on the MEAN WELL DDRH-30-48ST please view the datasheet
Other models in the DDRH-30(ST) series: 150~1500Vdc in, 12Vdc out-DDRH-30-12ST;, 150~1500Vdc in, 15Vdc out-DDRH-30-15ST;, 150~1500Vdc in, 24Vdc out-DDRH-30-24ST;
| Price | $50.20 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| Power Output (W) | 30 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 150~1500 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 0.625A |
| Length | 5.31in (135.00mm) |
| Width | 2.76in (70.00mm) |
| Height | 1.26in (32.00mm) |
| Operating Temperature | -40C ~ 80C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 0.672525 |
| Product Series | DDRH-30(ST) |
Get Help Finding the Right Power Supply: Power Requirement Form
