Mean Well DDRH-30-12P (30W 12V)
SKU
DDRH-30-12P
$44.10
- Buy 5 for $42.00 each and save 5%
- Buy 10 for $40.10 each and save 9%
- Buy 20 for $39.00 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, On Board Package, 30 Watts, Input Voltage Range: 150~1500VDC, Output Voltage: 12VDC, Output Current: 2.5A
More Details
The MEAN WELL DDRH-30-12P is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 150 VDC and 1500 VDC with a nominal input of 800 volts. The DDRH-30-12P has a 12 Volt Output at 2.5 amps (30 watts). The operating temperature is -40~+80°C and comes with several safety marks including EAC/CE/UKCA. The DDRH-30-12P, DC-DC converter, has a Board Mount package type and its dimensions are 3.50 (L) x 2.50 (W) x 0.98 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL DDRH-30-12P Features
View More
For specific information on the MEAN WELL DDRH-30-12P please view the datasheet
Other models in the DDRH-30(P) series: 150~1500Vdc in, 15Vdc out-DDRH-30-15P;, 150~1500Vdc in, 24Vdc out-DDRH-30-24P;, 150~1500Vdc in, 48Vdc out-DDRH-30-48P;
| Price | $44.10 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | On Board |
| Power Output (W) | 30 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 150~1500 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 2.5A |
| Length | 3.50in (89.00mm) |
| Width | 2.50in (63.50mm) |
| Height | 0.98in (25.00mm) |
| Operating Temperature | -40C ~ 80C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 0.529200 |
| Product Series | DDRH-30(P) |
Get Help Finding the Right Power Supply: Power Requirement Form
