Mean Well DDRH-240-12 (200W 12V)
SKU
DDRH-240-12
Authorized MEAN WELL
Stocking Distributor
$89.30
- Buy 5 for $85.10 each and save 5%
- Buy 10 for $81.30 each and save 9%
- Buy 20 for $79.00 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, DIN Rail Package, 200 Watts, Input Voltage Range: 250~1500VDC, Output Voltage: 12VDC, Output Current: 16.7A
More Details
The MEAN WELL DDRH-240-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 250 VDC and 1500 VDC with a nominal input of 700 volts. The DDRH-240-12 has a 12 Volt Output at 16.7 amps (200 watts). The operating temperature is -40~+80°C and comes with several safety marks including DEKRA/EAC/CB/CE/UKCA. The DDRH-240-12, DC-DC converter, has a DIN Rail package type and its dimensions are 5.09 (L) x 3.37 (W) x 4.93 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL DDRH-240-12 Features
View More
For specific information on the MEAN WELL DDRH-240-12 please view the datasheet
Other models in the DDRH-240 series: 250~1500Vdc in, 24Vdc out-DDRH-240-24;, 250~1500Vdc in, 32Vdc out-DDRH-240-32;, 250~1500Vdc in, 48Vdc out-DDRH-240-48;
| Price | $89.30 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| Power Output (W) | 200 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 250~1500 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 16.7A |
| Length | 5.09in (129.20mm) |
| Width | 3.37in (85.50mm) |
| Height | 4.93in (125.20mm) |
| Operating Temperature | -40C ~ 80C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 2.120000 |
| Product Series | DDRH-240 |
Get Help Finding the Right Power Supply: Power Requirement Form
