Enclosed DC-DC

Items 1-9 of 176

Set Descending Direction
  1. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 20A 9~14VDC input 12VDC output

    More Details
    The MEAN WELL ERDN20-12 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 12 Volts or can accept an input voltage between 9 VDC and 14 VDC. The ERDN20-12 has an output voltage of 12 VDC at 20 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN20-12 DC-DC converter is a Enclosed package type and its dimensions are 82 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  2. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 20A 19~29VDC input 24VDC output

    More Details
    The MEAN WELL ERDN20-24 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 24 Volts or can accept an input voltage between 19 VDC and 29 VDC. The ERDN20-24 has an output voltage of 24 VDC at 20 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN20-24 DC-DC converter is a Enclosed package type and its dimensions are 82 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  3. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 20A 36~60VDC input 48VDC output

    More Details
    The MEAN WELL ERDN20-48 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 48 Volts or can accept an input voltage between 36 VDC and 60 VDC. The ERDN20-48 has an output voltage of 48 VDC at 20 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN20-48 DC-DC converter is a Enclosed package type and its dimensions are 82 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  4. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 20A 4.5~6VDC input 5VDC output

    More Details
    The MEAN WELL ERDN20-5 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 5 volts or can accept an input voltage between 4.5 VDC and 6 VDC. The ERDN20-5 has an output voltage of 5 VDC at 20 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN20-5 DC-DC converter is a Enclosed package type and its dimensions are 82 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  5. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 40A 9~14VDC input 12VDC output

    More Details
    The MEAN WELL ERDN40-12 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 12 Volts or can accept an input voltage between 9 VDC and 14 VDC. The ERDN40-12 has an output voltage of 12 VDC at 40 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN40-12 DC-DC converter is a Enclosed package type and its dimensions are 97 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  6. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 40A 19~29VDC input 24VDC output

    More Details
    The MEAN WELL ERDN40-24 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 24 Volts or can accept an input voltage between 19 VDC and 29 VDC. The ERDN40-24 has an output voltage of 24 VDC at 40 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN40-24 DC-DC converter is a Enclosed package type and its dimensions are 97 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  7. MEAN WELL DC-DC Industrial Enclosed type redundancy module up to 40A 36~60VDC input 48VDC output

    More Details
    The MEAN WELL ERDN40-48 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 48 Volts or can accept an input voltage between 36 VDC and 60 VDC. The ERDN40-48 has an output voltage of 48 VDC at 40 amps ( watts). The operating temperature is -40~+80°C and comes with several safety marks including UR/CB/CE/EAC. The ERDN40-48 DC-DC converter is a Enclosed package type and its dimensions are 97 (L) x 99 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  8. MEAN WELL DC-DC Industrial Enclosed 100 watts 16.8~31.2VDC input 12VDC output

    More Details
    The MEAN WELL RSD-100B-12 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 24 Volts or can accept an input voltage between 16.8 VDC and 31.2 VDC. The RSD-100B-12 has an output voltage of 12 VDC at 8.4 amps (100 watts). The operating temperature is -40~+70°C and comes with several safety marks including CE. The RSD-100B-12 DC-DC converter is a Enclosed package type and its dimensions are 161 (L) x 68 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
  9. MEAN WELL DC-DC Industrial Enclosed 100 watts 16.8~31.2VDC input 24VDC output

    More Details
    The MEAN WELL RSD-100B-24 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 24 Volts or can accept an input voltage between 16.8 VDC and 31.2 VDC. The RSD-100B-24 has an output voltage of 24 VDC at 4.2 amps (100 watts). The operating temperature is -40~+70°C and comes with several safety marks including CE. The RSD-100B-24 DC-DC converter is a Enclosed package type and its dimensions are 161 (L) x 68 (W) x 36 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).
